部署LVS+Keepalived节点

安装步骤如下: ln -s /usr/src/kernels/(现有内核)/ /usr/src/linux 下载 wget http://www.linuxvirtualserver.org/software/kernel-2.6/ipvsadm-1.24.tar.gz wget http://www.keepalived.org/software/keepalived-1.1.15.tar.gz 安装与启动 tar zxvf ipvsadm-1.24.tar.gz cd ipvsadm-1.24 make make install cd .. tar zxvf keepalived-1.1.15.tar.gz cd keepalived-1.1.15 ./configure make make install cp /usr/local/etc/rc.d/init.d/keepalived /etc/rc.d/init.d/ cp /usr/local/etc/sysconfig/keepalived /etc/sysconfig/ mkdir /etc/keepalived cp /usr/local/etc/keepalived/keepalived.conf /etc/keepalived/ cp /usr/local/sbin/keepalived /usr/sbin/ service keepalived start

2010-03-12 · 1 min · 47 words · kevin

部署Func/Certmaster平台

Func简介 Func是由红帽子公司以Fedora平台统一网络控制器 Func(Fedora Unified Network Controller https://fedorahosted.org/func),目的是为了解决这一系列统一管理监控问题而设计开发的系统管理基础框架。 它是一个能有效的简化我们多服务器系统管理工作的工具,它很容易学习、很容易使用、也很容易被扩展,它功能强大而我们只需要非常非常少的配置和维护。 Func分为master及slave两部分,master为主控端,slave为被控端。以下为两部分的安装配置说明 一、Func 2.5版本安装文档[Master] 下载软件包 wget http://people.fedoraproject.org/~alikins/files/certmaster/certmaster-0.25.tar.gz wget http://people.fedoraproject.org/~alikins/files/func/func-0.25.tar.gz wget http://ovh.dl.sourceforge.net/sourceforge/pyopenssl/pyOpenSSL-0.9.tar.gz 安装 tar -zxvf pyOpenSSL-0.9.tar.gz cd pyOpenSSL-0.9 /usr/local/bin/python setup.py install tar -zxvf certmaster-0.25.tar.gz cd certmaster-0.25 /usr/local/bin/python setup.py install tar -zxvf func-0.25.tar.gz cd func-0.25 /usr/local/bin/python setup.py install 配置 vi /etc/certmaster/certmaster.conf [main] autosign = no listen_addr = #证书交换通讯端口 listen_port = 1998 cadir = /etc/pki/certmaster/ca cert_dir = /etc/pki/certmaster certroot = /var/lib/certmaster/certmaster/certs csrroot = /var/lib/certmaster/certmaster/csrs cert_extension = cert sync_certs = False vi /etc/func/minion.conf [main] log_level = DEBUG acl_dir = /etc/func/minion-acl.d listen_addr = #(Func通讯端口 listen_port = 1999 minion_name = 启动服务 ...

2010-03-12 · 2 min · 228 words · kevin

DD命令详解

1.命令简介 dd 的主要选项: 指定数字的地方若以下列字符结尾乘以相应的数字: b=512, c=1, k=1024, w=2, xm=number m if=file #输入文件名,缺省为标准输入。 of=file #输出文件名,缺省为标准输出。 ibs=bytes #一次读入 bytes 个字节(即一个块大小为 bytes 个字节)。 obs=bytes #一次写 bytes 个字节(即一个块大小为 bytes 个字节)。 bs=bytes #同时设置读写块的大小为 bytes ,可代替 ibs 和 obs 。 cbs=bytes #一次转换 bytes 个字节,即转换缓冲区大小。 skip=blocks #从输入文件开头跳过 blocks 个块后再开始复制。 seek=blocks #从输出文件开头跳过 blocks 个块后再开始复制。(通常只有当输出文件是磁盘或磁带时才有效)。 count=blocks #仅拷贝 blocks 个块,块大小等于 ibs 指定的字节数。 conv=conversion[,conversion…] #用指定的参数转换文件。 转换参数: ascii 转换 EBCDIC 为 ASCII。 ebcdic 转换 ASCII 为 EBCDIC。 ibm 转换 ASCII 为 alternate EBCDIC. block 把每一行转换为长度为 cbs 的记录,不足部分用空格填充。 unblock 使每一行的长度都为 cbs ,不足部分用空格填充。 lcase 把大写字符转换为小写字符。 ucase 把小写字符转换为大写字符。 swab 交换输入的每对字节。 noerror 出错时不停止。 notrunc 不截短输出文件。 sync 把每个输入块填充到ibs个字节,不足部分用空(NUL)字符补齐。 ...

2010-01-26 · 2 min · 264 words · kevin

定制自己的LiveCD,依托(centos)

1、建立自己的yum-repository或者使用官方的(考虑到你需要的软件小,所以这一步不是很必要)。 2、安装一个centos系统,修改etc/yum.repos.d/centos-livecd.repo文件内容 # Name: CentOS LiveCD repository [livecd] name = CentOS $releasever - LiveCD baseurl = http://www.nanotechnologies.qc.ca/propos/linux/centos-live/$basearch/live enabled=1 protect=0 gpgkey = http://www.nanotechnologies.qc.ca/propos/linux/RPM-GPG-KEY-PGuay 保存之后,执行以下命令: # yum install livecd-tools syslinux 这样就安装好了工具,接下来就是写自己想要的ks脚本; 3、ks脚本 名称:centos-livecd-minimal.ks(包含必须包的脚本) 内容: lang en_US.UTF-8 keyboard us timezone US/Eastern auth --useshadow --enablemd5 selinux --disabled firewall --disabled repo --name=base --baseurl=http://ftp.telus.net/pub/centos/5/os/$basearch repo --name=updates --baseurl=http://ftp.telus.net/pub/centos/5/updates/$basearch repo --name=extras --baseurl=http://ftp.telus.net/pub/centos/5/extras/$basearch #repo --name=base --baseurl=http://isoredirect.centos.org/centos/5/os/$basearch #repo --name=updates --baseurl=http://isoredirect.centos.org/centos/5/updates/$basearch #repo --name=extras --baseurl=http://isoredirect.centos.org/centos/5/extras/$basearch repo --name=live --baseurl=http://www.nanotechnologies.qc.ca/propos/linux/centos-live/$basearch/live %packages bash kernel syslinux passwd policycoreutils chkconfig authconfig rootfiles comps-extras xkeyboard-config gnome-desktop 4、生成 ...

2010-01-20 · 1 min · 86 words · kevin

Nginx整合Resin

操作系统:centos 5.4 64位 1,安装jdk,已经配置有yumrepository,直接使用。 yum install jdk 2,安装pcre,nginx运行所需perl库。 yum install pcre pcre-devel 3,安装mysql ,mysql相关配置省略。 yum install mysql mysql-server 4,安装并配置resin。 wget http://www.caucho.com/download/resin-4.0.3.tar.gz tar zxvf resin-4.0.3.tar.gz cd resin-4.0.3 ./configure --prefix=/usr/local/resin make && make install 修改配置参数 vi /usr/local/resin/conf/resin.xml 注释掉下面代码,不然会提示启动错误 www-data www-data 并添加相应配置 启动resin /usr/local/resin/bin/resin.sh start 5,安装nginx。 wget http://nginx.org/download/nginx-0.8.32.tar.gz tar zxvf nginx-0.8.32.tar.gz ./configure --prefix=/usr/local/nginx make && make install 修改配置文件 vi /usr/local/nginx/conf/proxy proxy_redirect off; proxy_set_header Host $host; proxy_set_header X-Real-IP $remote_addr; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; client_max_body_size 10m; client_body_buffer_size 128k; proxy_connect_timeout 90; proxy_send_timeout 90; proxy_read_timeout 90; proxy_buffers 32 4k; vi /usr/local/nginx/conf/nginx 修改server { … …} 为下面代码 ...

2010-01-20 · 1 min · 124 words · kevin

linux下的无盘工作站配置(centos)

 需求:需要多个系统同运行同样的服务,如j2ee模块、memcached等,这些服务不与硬盘相关,只运行在内存中,并且多个系统同时运行,为了规避单点故障以及实现高效。 下面步骤是centos5.4系统的无盘服务端配置步骤,客户端只要选择从网络启动,即可在无干预情况下启动系统。 一,新建主要目录 mkdir -p /diskless/x86_64/centos5.4/root mkdir /diskless/x86_64/centos5.4/snapshot 二,拷贝预置模板到/diskless/x86_64/centos5.4/root目录 rsync -auv -e ssh --delete --exclude='/proc/*' --exclude='/sys/*' --exclude='/tmp/*'--exclude='/var/log/*' root@10.0.70.72:/ /diskless/x86_64/centos5.4/root/ 三,配置所需tftp服务 yum -y install tftp tftp-server yum -y install busybox vi /etc/xinetd/tftp diskable=no chkconfig --level 345 xinetd on chkconfig --level 345 tftp on service xinetd start 四,配置dhcp服务 yum -y install dhcp-server chkconfig --level 345 dhcpd on vi /etc/dhcpd.conf allow booting; allow bootp; class “pxeclients” { match if substring(option vendor-class-identifier, 0, 9) = “PXEClient”; next-server <server-ip>; filename “linux-install/pxelinux.0”; } service dhcpd start ...

2009-12-29 · 2 min · 328 words · kevin

Oracle 11g Software Installation on Linux—CentOS-5

Introduction This paper takes a look at installing oracle 11g (11.1) on Linux (CentOS-5).You can read about CentOS at www.centos.org and be assured of its’ Enterprise-class quality. This paper will use oracle’s Quick Installation Guide for Linux x86 as its’ guide—noting where additional information may be obtained but getting oracle installed on Linux as fast as possible. We at thecheapdba.com have years of experience installing oracle—starting back with oracle 7. We will point out best practices so that you end up with a reliable database that provides exceptional performance. We will occasionally re-visit, edit, and post additions to this paper as we find further configuration best practices. This paper will not cover the installation of CentOS-5 as that can be acquired through the CentOS website and additional Linux guides. We will however point out those alterations to the Linux environment that pertains to getting oracle installed. Our goal is to provide you with the steps to properly install the oracle 11g software without having to read oracle’s installation guide from front to back cover. We will provide you the commands to execute (just cut-n-paste) and the desired outcome of those commands. If you get something other than what is expected it would be time for you to re-visit earlier steps in this process. So hold on, here we go. It is assumed that the installer of oracle software has access and is running on an X Window System workstation. Please consult X Server documentation if you need help. We at thecheapdba.com typically will use cygwin ( www.cygwin.com ) for all interfacing with our Linux distribution. It has an X Window System that works quite well—and as we always like is free. Checking Hardware Requirements Log into the CentOS-5 system as the root user. For setting up the system to be used by oracle there are a few prerequisites that must be checked and possibly changed by the root user. Log in as the root user and this document will tell you when it is time to switch from the root user to someone else. How much memory command: grep -i memtotal /proc/meminfo results: should be at least 1GB How much swap command: grep -i swaptotal /proc/meminfo results: should be 1.5 the size of memtotal if memtotal < 2GB should be equal to memtotal if memtotal is between 2GB and 8GB should be .75 the size of memtotal if memtotal > 8GB What processor type command: grep “model name” /proc/cpuinfo results: informational How much available RAM and swap command: free results: informational How much shared memory available command: df -k /dev/shm results: informational purpose: The shared memory should be sized to be at least the greater of MEMORY_MAX_TARGET and MEMORY_TARGET for each oracle instance on the computer. How much disk space in /tmp command: df -k /tmp results: should have at least 400MB available How much disk space for oracle binaries command: df -k results: Depending on installation type you should have between 1.5GB and 3.5GB Checking Software Requirements What distribution and version of Linux is installed command: cat /proc/version results: Linux version 2.6.18-8.1.15.el5 (mockbuild@builder6.centos.org) (gcc version 4.1.1 20070105 (Red Hat 4.1.1-52)) #1 SMP Mon Oct 22 08:32:04 EDT 2007 What version of the kernel is installed command: uname -r results: 2.6.18-8.1.15.el5 Are the following packages installed (assumes CentOS-5 and above distribution) command:rpm -q binutils \ compat-libstdc++ \ elfutils-libelf \ elfutils-libelf-devel \ glibc \ glibc-common \ glibc-devel \ glibc-headers \ gcc \ gcc-c++ \ libaio-devel \ libaio \ libgcc \ libstdc++ \ libstdc++ \ make \ sysstat \ unixODBC \ unixODBC-devel results: you will probably get quite a few packages that are not installed with a typical installation. You can investigate missing packages with the following command making sure you add/subtract from this list if necessary. yum list available “compat*” \ “elfutils*” \ “glibc*” \ “gcc*” \ “libaio*” \ “sysstat*” \ “unixODBC*” action : Our base installation left us needing to issue the following command to install missing packages. yum -y install compat-libstdc++-296.i386 \ compat-libstdc++-33.i386 \ elfutils-libelf-devel.i386 \ glibc-devel.i386 \ glibc-headers.i386 \ gcc.i386 \ gcc-c++.i386 \ libaio-devel.i386 \ sysstat.i386 \ unixODBC.i386 \ unixODBC-devel.i386 Create oracle user and group Create groups oinstall & dba command: /usr/sbin/groupadd oinstall /usr/sbin/groupadd dba Create the oracle and change password command: /usr/sbin/useradd -g oinstall -G dba -s /bin/bash oracle /usr/bin/passwd oracle Validate the nobody user exists command: /usr/bin/id nobody results: this user is almost always created on a base CentOS installation action : if this user is not created use the following command to create /usr/sbin/useradd nobody Configuring kernel parameters The following kernel parameters must be validated and possibly changed. Use the commands given below to view a particular kernel setting and then change if the setting is lower than the recommendation given in the following table. You can make the changes by editing the /etc/sysctl.conf file and then rebooting the server. The following results are what we observed on our server and should not be expected on yours. shmmni 4096 shmall 2097152 shmmax 2147483648 semmsl 250 semmns 32000 semopm 100 semmni 128 file-max 65536 ip_local_port_range 1024 - 65000 rmem_default 1048576 rmem_max 1048576 wmem_default 262144 wmem_max 262144 command: /sbin/sysctl -a | grep kernel.sem results: kernel.sem = 250 32000 100 128 command: /sbin/sysctl -a | grep kernel.shm results: kernel.shmmni = 4096 kernel.shmall = 268435456 kernel.shmmax = 4294967295 command: /sbin/sysctl -a | grep file-max results: fs.file-max = 102440 command: /sbin/sysctl -a | grep ip_local_port_range results: net.ipv4.ip_local_port_range = 32768 61000 command: /sbin/sysctl -a | grep rmem_default results: net.core.rmem_default = 109568 command: /sbin/sysctl -a | grep rmem_max results: net.core.rmem_max = 131071 command: /sbin/sysctl -a | grep wmem_default results: net.core.wmem_default = 109568 command: /sbin/sysctl -a | grep wmem_max results: net.core.wmem_max = 131071 sample /etc/sysctl.conf file. This is given as an example only and does not reflect the results obtained above by the /sbin/sysctl commands. Only add lines that are needed and do not change any values to be lower than the base installation might have assigned. kernel.shmall = 2097152 kernel.shmmax = 2147483648 kernel.shmmni = 4096 kernel.sem = 250 32000 100 128 fs.file-max = 65536 net.ipv4.ip_local_port_range = 1024 65000 net.core.rmem_default = 4194304 net.core.rmem_max = 4194304 net.core.wmem_default = 262144 net.core.wmem_max = 262144 Setting shell limits for the oracle user Add the following lines to /etc/security/limits.conf oracle soft nproc 2047 oracle hard nproc 16384 oracle soft nofile 1024 oracle hard nofile 65536 Add the following lines to /etc/pam.d/login session required /lib/security/pam_limits.so session required pam_limits.so Add the following lines to /etc/profile if [ $USER = “oracle” ]; then if [ $SHELL = “/bin/ksh” ]; then ulimit -p 16384 ulimit -n 65536 else ulimit -u 16384 -n 65536 fi fi Creating Directories to Install the oracle Software Validate you have enough space on disk and choose a directory to install command: df -k results: pick a mount point that has enough space—we have chosen /opt for the our. Create subdirectories and give permissions to the oracle user The following directory used is common for oracle installations. Note that we are creating all directories under /opt and that there are no other applications using /opt/app and below. This is very important as we are changing permissions with the following commands. command: mkdir -p /opt/app/oracle/product/11.1.0 chown -R oracle:oinstall /opt/app chmod -R 775 /opt/app Switch to the oracle user Up to know we have been doing everything as the root user. It is now time to switch to the oracle user to actually install the oracle software. command: su – oracle Add the following line to $HOME/.bash_profile umask 022 Execute oracle’s bash_profile to use new setting command: . ./.bash_profile Make sure the oracle user is using an X Windows System It is assumed you know how to set up an X Windows System as stated earlier in the document. Please verify it is working by issuing the xterm command and validating an X Terminal comes up. You may close the X Terminal if you wish. Set oracle environment for the installation Issue the following commands to set/unset particular oracle environments in preparation for the installation. command: export orACLE_BASE=/opt/app/oracle export orACLE_SID=orcl unset orACLE_HOME unset TNS_ADMIN Start oracle Installer This paper assumes you have downloaded the oracle software from the net and have unzipped the files. We have unzipped our software into /opt and the following commands will take you through starting the oracle installer form that mount point. command: cd /opt/database ./runInstaller From this point, oracle will do a few minor checks on the operating system and then put up the oracle Installation screen. Our particular configuration did not throw any errors at this point but it should be noted, as it can be helpful, that sometimes the oracle installer will complain at this very early stage about various Linux system configurations. If this is the case you might be able to bypass them by adding an additional argument to the runInstaller command. Please only use this as a last resort to the normal installation path. command: ./runInstaller -ignoreSysPrereqs From this point on we will walk through each of the prompts one at a time to give you a simple feel for a full installation of the oracle software. Select installation method This screen is very busy to say the least. We are not going to create any databases at this point as it is not required nor is it suggested to do at this point. We like to create databases separately through the Database Creation Assistant (DBCA) and not confuse the software installation process. 1. Choose basic installation 1. verify oracle Base of ‘/opt/app/oracle’ 2. verify oracle Home of ‘/opt/app/oracle/product/11.1.0/db_1’ 3. verify installation type of ‘Enterprise Edition’ 4. verify dba group of ‘dba’ 2. Un-check “Create Starter Database” 3. Un-check “Advanced Installation” 4. Click Specify Inventory directory and credentials 1. verify path of inventory directory of ‘/opt/app/oraInventory’ 2. verify group name for install of ‘oinstall’ 3. Click Product-Specific Prerequisite Checks This screen, the installer will verify the system environment and report on any issues it may find. If all goes well you will get the status of ‘Succeeded’ for every check. Scroll through and make sure nothing has failed or look at the status box at the bottom of the screen and verify you get the following: ‘Check complete. The overall result of this check is: Passed’ 1. verify all statuses 2. Click Summary This screen give a summary of the installation you are about to perform. It can be interesting to click and expand the products being installed to give you an idea of the what product and version is going to be installed. 1. validate ‘Global Settings’ for directories 2. validate ‘Space Requirements’ 3. Click Install This screen gives a status of what is being installed. If all system settings have been properly set and all packages been installed properly then this should proceed without error. The status bar gives some indication of what is being installed at a particular point and the amount of work to be performed. But as all status bars you never really know how long in the process it is. 1. Note the time it takes for specific products. If you notice one hanging or taking a long amount of time (greater than 10 minutes) you could have a condition that requires a pre-installation patch. Don’t stop the installer yet but instead start looking for a bug / patch for the oracle 11g installation process and the actual product being installed. 2. Execute Configuration scripts 1. open up a different terminal window 2. login as the root user 3. run /opt/app/oraInventory/orainstRoot.sh 4. run /opt/app/oracle/product/11.1.0/db_1/root.sh 1. accept default of /usr/local/bin 5. Click 3. Click 4. Click Cleanup 1. If you downloaded the software from the net you can now remove .zip file and the complete directory structure you unzipped it to. That particular command is not given here as it can be quite disastrous if executed from the wrong directory. 2. Add the following lines to oracle’s $HOME/.bash_profile file. This will allow you to execute various oracle binaries to create databases, configure network settings, and generally manage the oracle database environment. export orACLE_HOME=/opt/app/oracle/product/11.1.0/db_1 export PATH=$ORACLE_HOME/bin:$PATH Installation is complete Congratulations on a successful installation of the oracle software. This paper hopefully was also successful in its attempt to guide you down a more simplistic path—giving you the commands to execute and working past the minor hurdles encountered during installation. Obviously this paper can not predict all the issues that you may encounter but if you have a relatively current system with ample memory and disk space there is no reason not to believe your installation wouldn’t run smoothly.

2009-12-07 · 10 min · 2083 words · kevin

linux/centos cacti备份及恢复shell

备份及恢复Cacti (1)cacti的文件目录的备份(rra目录除外) (2)mysql备份 mysqldump -p cacti >/tmp/cacti.sql (3)备份rra dumprrd.sh #!/bin/sh rrddump="/usr/local/bin/rrdtool dump" xmldir="/tmp/mysqlbackup/rraxml" xmlbackup="/tmp/mysqlbackup/rrabak" mysqlbackupDIR="/tmp/mysqlbackup" rrdpath="/usr/local/share/cacti/rra/" DATE=`date +"%y-%m-%d"` if [ ! -e {xmldir} fi if [ ! -e {xmlbackup} fi #create rra => xml for file in `find /usr/local/share/cacti/rra/ -mtime -2 | awk -F\/ ‘{print $NF}̵7;` do {rrdpath}{xmldir}/${file}.xml done if [ `ls /tmp/mysqlbackup/rraxml/|wc -l` -ge 2 ];then #tar backup cd ${mysqlbackupDIR} tar czvf {DATE}.tar.gz rraxml >/dev/null 2>&1 mv {DATE}.tar.gz ${xmlbackup} #delete file&dir if [ $? -eq 0 ];then rm -fdr {xmldir} /usr/bin/find ${mysqlbackupDIR}/rrabak -type f -ctime +2 | /usr/bin/xargs /bin/rm >/dev/null 2>&1 echo “Rra Backup is ok!” fi else echo “Rra Backup is fail!” fi ...

2009-11-23 · 1 min · 132 words · kevin
